Dräger Polytron 8200 CAT

The Dräger Polytron 8200 belongs to the Polytron 8000 series. All transmitters in this series have the same design and user interface. This allows for uniform operation with reduced training and maintenance requirements. The large graphic backlit display shows status information clearly and in an easy to use format. The measured gas concentration and measuring unit are displayed during normal operation. Coloured LEDs (green, yellow and red) provide additional alarm and status information. You can evaluate the sensor signal by using the 4 to 20 mA output. The Polytron 8200 is operated by means of a magnetic wand over contact surfaces.

Upon request, the Dräger Polytron 8200 can also be supplied with three integrated relays. This enables you to use it as an independent gas detection system with two arbitrarily adjustable concentration alarms and one fault alarm. Audible alarms, signal lights or similar devices can thus be controlled locally without an additional cable between the transmitter and central controller.

The Polytron 8200 is explosion-proof and conforms to explosion protection type "d". For the increased safety type 'e' protection, an additional terminal box is available. This also makes pre-assembly easier. Depending on the environmental conditions, you can choose the Dräger Polytron 8200 with either an aluminium or stainless steel housing.

The remote sensing head allows you to install the sensor separately from the transmitter. This allows you to simply place the sensor closer to the gas cloud in hard-to-reach locations. The display remains visible at eye level.

The Polytron 8200 has a data logger, which records measuring and event data from prior years.
